Hammer 200L

The Hammer 200L stands out with an exceptional 295mm ground clearance, delivering superior off-road capability in its class. The 196cc engine, hydraulic suspension, and elevated chassis ensure confident performance on rough, grassy, or uneven terrain. Lightweight yet durable, it is perfect for farm tasks, onsite transport, and terrain inspection.

  • Performance features
  • Parameters
  • Accessories

Parameters

· Engine

Engine Type1-Cylinder,4-Stroke,Oil Cooling
Displacement177.3 cm3
Bore And Stroke62.5 mm x 57.4 mm
Compression Ratio10:1
Maximum HorsePower9.7 HP @ 7500 r/min
Maximum Torque10 NM @ 6000 r/min
Fuel SupplyCarburetor
Start SystemElectric Start
TransimissionChain Drive

· Chassis

Front SuspensionDual A Arms Independent Suspension
Rear SuspensionSwing Arm
Front BrakeHydraulic Disc Brake
Rear BrakeHydraulic Disc Brake
Front Tires21x7-10
Rear Tires22x10-10

· Dimensions / Capacity

LxWxH1870x1050x1400 mm
Wheelbase1180 mm
Ground Clearance295 mm
Maximum Speed60 km/h
Net Weight197 kg
Fuel Tank Capacity9.7 L
Maximum Load Capacity100 kg
40HQ42 Units
